Why Siege isn't an accurate test tool for Magento performance
We're getting pretty concerned at Sonassi HQ with the growing confusion surrounding transactions per second (TPS), requests per second (RPS) and concurrency by the community as a whole. Shamefully, I fear that we are guilty for bucking this trend.
We created a monster, now its time to put it down
3 years ago, when we really started to get engaged in web hosting, we launched a little project called Mage Benchmark. The purpose was to have a portal where specialist Magento web hosts could put a brief description about themselves and volunteer a URL for a self-hosted demo store - that could be externally tested to give a viewpoint of uptime, page load time and concurrency support. This attracted both acclaim and sadly, criticism, amongst the community.
Early on, before Mage Benchmark, Sonassi and Pro Contractors (two high performance, specialist Magento web hosts) had spurred a trend of performance testing using Siege. It served a purpose, for quick and easy testing of server-side changes and showing performance differences for high levels of concurrency. So when you are testing your own servers, its fairly useful - but its not without its faults.
That is why we launched Mage Benchmark, so that we could test not only pure PHP throughput via a "Siege-like" test, but also complete full page downloads and replicate the user experience. Originally, it was built on a custom shell application, but now we use Apache jMeter to carry this testing out.
Siege is great
Siege really is a great tool, but what is isn't is a tool that is designed to test remote locations, at high levels of concurrency, with any accuracy. In fact, it has a number of shortfalls when used in this capacity.
Siege isn't representative of what a real-user (or multiple users) would actually be doing** on your website. It can only load the raw response code and HTML, not all the other elements within a page (images, CSS, JS or other static content) - so effectively, it only tests PHP performance.
It also has very limited session/cookie support, no support for pipelining and basic support for HTTP/1.1. The load it is generating is nothing like that of a real-user, so whilst its good for a quick reference after changes; it doesn't really indicate that anything will change for a user in real life.
Siege is easily fooled
It can't differentiate between a static file being served (ie. a pure HTML file) or a dynamic file (ie. a dynamic Magento PHP page). So if you are running any kind of static file proxy, the results are immediately skewed. At this point - you'll only be testing the caching proxy, not the delivery speed behind it.
So those using Varnish, Nginx caching, mod_pagecache can easily just buffer the page into a cache and you'll see sub 20ms render times. If your using Varnish, then using Siege to test performance - you might as well be loading an image rather than category URL, as it'll give the exact same results.
Testing remote servers is almost pointless
As it is a concurrency test (ie. how many requests can be satisfied repeatedly), the immediate bottleneck is the network connection between the two machines. Latency and TCP/IP overheads are what make testing a remote site completely pointless, the slightest network congestion amongst a peer between the two servers will immediately show reduced performance. So, what really starts to come into play is how fast the TCP 3-way handshake can be completed - the server being tested could be serving a dynamic page or static 0 byte file - and you could see exactly the same rates of performance, as connectivity is the bottleneck.
We can show this using a simple ping
. Our data-centres are located in Manchester, United Kingdom, so we'll try pinging a server in the UK, then a server in the USA and show the differentiation. Both servers are connected to the internet via 100Mbit connections.
Ping from UK to UK
[~]$ ping www.bytemark.co.uk -c4
PING www.bytemark.co.uk (212.110.161.177) 56(84) bytes of data.
64 bytes from extapp-front.bytemark.co.uk (212.110.161.177): icmp_seq=1 ttl=57 time=2.86 ms
64 bytes from extapp-front.bytemark.co.uk (212.110.161.177): icmp_seq=2 ttl=57 time=2.51 ms
64 bytes from extapp-front.bytemark.co.uk (212.110.161.177): icmp_seq=3 ttl=57 time=2.54 ms
64 bytes from extapp-front.bytemark.co.uk (212.110.161.177): icmp_seq=4 ttl=57 time=2.63 ms
--- www.bytemark.co.uk ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3005ms
rtt min/avg/max/mdev = 2.515/2.641/2.869/0.142 ms
Ping from UK to USA
[~]$ ping www.mediatemple.net -c 4
PING www.mediatemple.net (64.207.129.182) 56(84) bytes of data.
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=1 ttl=49 time=158 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=2 ttl=49 time=154 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=3 ttl=49 time=154 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=4 ttl=49 time=154 ms
--- www.mediatemple.net ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3004ms
rtt min/avg/max/mdev = 154.155/155.282/158.321/1.802 ms
You can immediately see the difference in performance. For that single TCP/IP connection to the USA from the UK, it took 156ms, 62 times more than to a server in the UK. Which means that before you even try anything, the maximum throughput you can achieve on Siege in a second is going to be around 6 transactions per second, due to latency alone.
Lets put this to the test then ...
[~]$ siege [https://mediatemple.net/](https://mediatemple.net/) -c 1 -t 10S -b
**SIEGE 2.66** Preparing 1 concurrent users for battle.
The server is now under siege...
Lifting the server siege... done.
Transactions: 31 hits
Availability: 100.00 %
Elapsed time: 10.37 secs
Data transferred: 0.12 MB
Response time: 0.33 secs
Transaction rate: 2.99 trans/sec
Throughput: 0.01 MB/sec
Concurrency: 0.99
Successful transactions: 31
Failed transactions: 0
Longest transaction: 0.71
Shortest transaction: 0.31
Well, a bit disappointing there, we've only managed to load 3 transactions per second. But this could be down to a slow-to-render dynamic web page, so lets test a static element ([https://mediatemple.net/_images/searchicon.png](https://mediatemple.net/_images/searchicon.png)
) of the same size instead (4KB).
[~]$ siege [https://mediatemple.net/_images/searchicon.png](https://mediatemple.net/_images/searchicon.png) -c 1 -t 10S -b
**SIEGE 2.66** Preparing 1 concurrent users for battle.
The server is now under siege...
Lifting the server siege... done.
Transactions: 32 hits
Availability: 100.00 %
Elapsed time: 10.46 secs
Data transferred: 0.10 MB
Response time: 0.32 secs
Transaction rate: 3.06 trans/sec
Throughput: 0.01 MB/sec
Concurrency: 0.97
Successful transactions: 32
Failed transactions: 0
Longest transaction: 0.48
Shortest transaction: 0.30
Well, sadly, that's the same too. But perhaps it is the host that is the problem, lets try another website in the US and use a much smaller file (0.06KB) and see.
[~]$ siege [https://www.wiredtree.com/images/arrow.gif](https://www.wiredtree.com/images/arrow.gif) -c 1 -t 10S -b
**SIEGE 2.66** Preparing 1 concurrent users for battle.
The server is now under siege...
Lifting the server siege... done.
Transactions: 50 hits
Availability: 100.00 %
Elapsed time: 9.89 secs
Data transferred: 0.00 MB
Response time: 0.20 secs
Transaction rate: 5.06 trans/sec
Throughput: 0.00 MB/sec
Concurrency: 1.00
Successful transactions: 50
Failed transactions: 0
Longest transaction: 0.20
Shortest transaction: 0.19
Much better this time, but still under the predicted figure of 6 TPS. But unfortunately, this is always going to be the case. The latency will always prove to ruin any concurrency test even if the remote server is capable of much more. Lets repeat the exact same test from a server in the USA to see how latency really affected the test. First up a quick ping,
[~]$ ping www.mediatemple.net -c 4
PING www.mediatemple.net (64.207.129.182) 56(84) bytes of data.
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=1 ttl=52 time=62.8 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=2 ttl=52 time=62.9 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=3 ttl=52 time=62.9 ms
64 bytes from mediatemple.net (64.207.129.182): icmp_seq=4 ttl=52 time=62.9 ms
--- www.mediatemple.net ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3067ms
rtt min/avg/max/mdev = 62.872/62.922/62.946/0.029 ms
[~]$ siege [https://mediatemple.net/_images/searchicon.png](https://mediatemple.net/_images/searchicon.png) -c 1 -t 10S -b
**SIEGE 2.72** Preparing 1 concurrent users for battle.
The server is now under siege...
Lifting the server siege... done.
Transactions: 73 hits
Availability: 100.00 %
Elapsed time: 9.62 secs
Data transferred: 0.22 MB
Response time: 0.13 secs
Transaction rate: 7.59 trans/sec
Throughput: 0.02 MB/sec
Concurrency: 0.99
Successful transactions: 73
Failed transactions: 0
Longest transaction: 0.14
Shortest transaction: 0.12
So there you have it, we've managed to double our transactions per second, without any server-side changes simply by using a server closer to the test site - showing how sensitive Siege is network latency.
Siege is going to be limited by the bandwidth available
On your test server and the remote server. So once you start hitting higher levels of throughput, the amount of content being downloaded starts to go up. In our examples above, 0.02MB was downloaded in 10 seconds - which is a tiny 0.16 Mbps (megabits per second). But when you start to increase the number of concurrent users, things can change radically and it is very easy to saturate the network connection - long before the server itself has reached its capacity.
So if the server you were testing from only had 20Mbit of usable bandwidth, you would probably see a maximum of about 500 req/s on the 4Kb resource mentioned earlier.
So what should you use to test
When testing locally
By all means use Siege, httperf or AB - they each have their limitations, but can generally give you a comparable view of PHP-only concurrency support. Unless you looking to test any hardware further upstream than your server; like testing your firewalls, routers, switches - you should be testing locally. You need to rule out all other possible influences/bottlenecks.
When testing remotely
By all means, use any tool listed above - but don't try and compare the result to what you saw when testing locally. You'll still have a TPS rate that you can use as a reference - but it isn't accurate or comparable to what you would see if actually testing locally. Also note, for the reasons listed above - you are very likely to experience a latency or capacity bottleneck - that will render your results fairly worthless.
Ultimately
Don't concern yourself with high concurrency, remote load testing - if that is a concern - speak to a specialist Magento web host who will do all the required specification and testing required to meet your requirements.
We recommend
Where you should focus your attention is on making the site that little bit faster for a single-user, the real-world page load time perceived by a human. For this, there are some great on-line test tools that will give you a great rounded impression of your site actually performs.
We use JMeter for all our local load testing and for complex unit testing, its a great all-round application.
And remember - caching isn't king
When it comes to Magento performance, a cache is just hiding the underlying issue - if you can't serve a page quickly to begin with, the cache isn't going to help much. There is always going to be a time when the cache is empty and that first (un-cached) request needs to be made.
So those using Varnish, Nginx caching, mod_pagecache etc. can easily just buffer the page into a cache and you'll see sub 20ms render times. If your using any caching application, then using Siege to test performance - you might as well be loading an image rather than category URL, as it'll give the exact same results. Unless you are specifically trying to test the throughput of your caching application, it should be disabled during the testing process, otherwise it will taint your results with an artificial figure.
Server side includes being the exception to this, but it certainly goes beyond the scope of this article (remote performance testing with Siege).
